Place of Origin:Zhejiang, China (Mainland) Brand Name:FEIHU
Model Number:FHPT-2646 Lift Mechanism:Scissor Lift
Lift Drive / Actuation:Hydraulic Power:48V DC/ 225Ah
Rated Loading Capacity:454kg Min. Lifting Height:2.26m
Max. Lifting Height:9.8m Table Size: 1.17m*3.18m
Overall Dimensions:2.26m*1.17m*2.26m Weight:2447
Certification:CE / ISO 9001 Warranty:One Year
After-sales Service Provided:No overseas service provided Wheelbase:1.85m
Width:1.17m Color:RED, YELLOW, BLUE GREEN
Hydraulic system capacity:17L Raise/lower speed:30/38 second
Turning radius:2.29m Gradeability-uphill stowed:30%
Drive speed raised/stowed:R:0.8km/h; S:3.5km/h Extension deck capacity:136kg
Maximum platform occupancy:2 persons
Product Application
Zero-emission electric operation. Proportional controls for lift and drive functions.
Front-wheel drive and zero inside turning radius. Multiple disc brakes provide smooth deceleration.
39 in (1m) roll-out platform extension on GS-2646. On-board diagnostics for easy troubleshooting.
Folding rails with full-height swing gate. Emergency stop at both platform and ground controls.
Universal 20 amp smart charger. Solid, non-marking tires.
Manual platform lowering valve. Tilt sensor with an audible alarm.
|
WORKING HEIGHT MAX
|
9.8M
|
PLATFORM HEIGHT MAX
|
7.8M
|
|
PLATFORM HEIGHT-STOWED
|
1.16M
|
PLATFORM LENGTH-OUTSIDE
|
2.26M
|
|
EXTENDED
|
3.18M
|
SLIDE-OUT PLATFORM EXTENSION DECK
|
0.96M
|
|
PLATFORM WIDTH-OUTSIDE
|
1.15M
|
TOEBOARD HEIGHT
|
0.15M
|
|
WEIGTH
|
2447KG
|
POWER SOURCE
|
48V DC 225Ah Capacity
|
|
HYDRAULIC SYSTEM CAPACITY
|
17L
|
NON-MARKING TIRES ROUGH TERRAIN
|
38*13*28CM
|
|
RAISE/LOWER SPEED
|
30/38 SECOND
|
TURNING RADIUS-OUTSIDE
|
2.29M
|
|
LIFT CAPACITY
|
454KG
|
EXTENSION DECK CAPACITY
|
136KG
|
|
HEIGHT-STOWED
|
2.26M
|
RAILS LOWERED
|
1.68M
|
|
LENGTH-STOWED
|
2.41M
|
PLATFORM EXTENDED
|
3.33M
|
|
WIDTH
|
1.17M
|
WHEELBASE
|
1.85M
|
|
GROUND CLEARANCE-CENTER
|
0.1
|
MAX PLATFORM OCCUPANCY
|
2 PERSON
|
ZERO-EMISSION ELECTRIC OPERATION
POWER SOURCE: 48V DC (FOUR 6V BATTERIES, 225Ah CAPACITY).
ZERO-EMISSION ELECTRIC OPERATION
EMERGENCY STOP AT BOTH PLATFORM AND GROUND CONTROLS
BASE-CONTROL PANEL
ANTI-FALSE TOUCH SAFETY LOCK
UP-CONTROL PANEL
LOW SPEED BUTTON
TILT SENSOR WITH AN AUDIBLE ALARM
NON-MARKING TIRES-ROUGH TERRAIN
FRONT-WHEEL DRIVE AND ZERO INSIDE TURNING RADIUS
MILTIPLE DISC BRAKES PROVIDE SMOOTH DECELERATION
ROLL-OUT PLATFORM
39IN (1M) ROLL-OUT PLATFORM EXTENSION ON FHPT-2646
TECHNICAL SERVICE ALL THE TIME.
