LVSW-100 Series Low Voltage Switches are lighting control devices that use conventional point-to-point low voltage wiring for control of single or multiple loads.

Features

• Wallplate sold separately
• Color: White, Light Almond, Ivory, Grey, Black
• Typical Applications: Indoor Use
• Input voltage: 24 VDC maximum, from panel
• Maximum contact operating current: 50 mA
• Maximum operating current (per LED): 30 mA
• Low voltage pushbutton switches for on/off control of one or more loads
• LED pilot light on each button
• Compatible with LP8 and LI Series lighting control panels
• Customizable, field replaceable buttons
• Single gang devices, compatible with standard decorator style face plates
• Appearance matches DLM LMSW-100 Series digital wall switches

Documents
